| Product specification | P4 | P6 | P10 | P15.6 | P16 | P20 | P32 | P20-60 |
| Pixel pitch | 4mm*4mm（x*y） | 6mm*6mm（x*y） | 10mm*10mm（x*y） | 15.6mm*15.6mm（x*y） | 16mm*16mm（x*y） | 20mm*20mm（x*y） | 32mm*32mm（x*y） | 20mm*60mm（x*y） |
| Pixel | 62500points/m2 | 27556 points/m2 | 10000 points/m2 | 4109 points/m2 | 3844points/m2 | 2500 points/m2 | 961points/m2 | 800points/m2 |
| LED specification | SMD1010 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) | SMD2122 (light drive in one) | SMD2121 (light drive in one) | SMD2121 (light drive in one) |
| Pixel composition | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G2B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Pixel resolution | 250*250/㎡ | 166*166/㎡ | 100*100/㎡ | 64*64/㎡ | 62*62/㎡ | 50*50/㎡ | 31*31/㎡ | 50*16/㎡ |
| Permeability | ≥85% | ≥85% | ≥90% | ≥90% | ≥90% | ≥95% | ≥95% | ≥95% |
| Box wiring mode | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) | Internal wiring (clean back) |
| Weight | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m3 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 | ≤ 3.5KG/m2 |
| White balance brightness | ≥4000cd/㎡ | ≥4000cd/㎡ | ≥4000cd/㎡ | ≥4000cd/㎡ | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥3000cd/㎡ | ≥2500cd/㎡ |
| Peak power consumption | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ | 400 W/㎡ |
| Average power consumption | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) | About 200 W/㎡(depending on the video source) |
| Refresh frequency | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s | ≥3840s |
| Grayscale level | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit | 16Bit |
| Brightness control level | Grade 0-255 | Grade 0-255 | Grade 0-255 | Grade 0-255 | Grade 0-255 | Grade 0-255 | Grade 0-255 | Grade 0-255 |
| Color temperature | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) | 3200K-8500K (adjustable) |
| Frame change frequency | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz |
| Viewing angle | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees | H-H140 degrees V-V140 degrees |
| Input signal | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video | DVI VGA, composite video |
| Protection grade | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 | IP30 |
| working temperature | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ | -20~50 ℃ |
| Theoretical service life | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours | 100000 hours |
