king-pro-series

  • King Pro Series
  • King Pro Series

King Pro Series


Product Specification:

Inquiry Now

KING PRO SERIES:

Ground-breaking Rental Led cabinet




KING Pro Series Design:
Corner protection
Independent power box
Side lock
Unique curved lock
Left and right switchable module
Led module lock
Details Images
Model No.
Apollo-I2.6
Apollo-I2.98
Apollo-I3.91
Apollo-I4.81
Pixel pitch
2.604mm
2.98mm
3.91mm
4.81mm
Pixel density
147475 pixel/sqm
112896 pixel/sqm
65410 pixel/sqm
43222pixel/sqm
Brightness
1200cd/sqm
1200cd/sqm
1500cd/sqm
1300cd/sqm
Scan
1/32
1/28
1/16
1/13
Panel Dimension(W*H*D)
500x500x85mm/19.7”x19.7”x3.4”
Panel resolution
192 x 192 pixels
168 x 168 pixels
128 x 128 pixels
104 x 104 pixels
Panel weight
8KG
Cabinet material
Die casting aluminum
Max power consumption
800w/sqm
Average power consumption
270w/sqm
Viewing angle
H: 120° V:120°
Refresh rate
5580Hz
Gray scale
16bits
IP rating
IP43
Operating temperature
-20℃ ~+60℃
Lifetime
100000hours (about 11 years)
Storage temperature
-20℃ ~ +60℃

Upgraded on the basis of our KING series’s features:

Corner Protection
Power box design
Left and right Switchable Module
Unique custom made curved lock
Led module lock




KING Pro Series:

The left and right module are switchable
front maintenance for outdoor usage
module lock to faster led modules
KING series:

Left module and Right module are not switchable





KING Pro series Advantages:

1. power supply and receiving card are installed in the box.
2.PCB board design instead of the flat wire connection among led modules, power supply and receiving card to eliminate the signal connection problem.
3.It is convenient to do maintenance in the face of big events. Only 3-5 seconds needed to replace an new one instead of taking a long time to loosing screws like the below picuture.
Normal panel:

Regular wire connection design brings terrible situation, especially when facing a big event.





KING Pro Series

module corner: corner protection design is avoiding and hits for modules’ corner, 100% protect LEDs
Competitors
No protection for modules
During transportation, it easily hits the corner of led module and breaks leds




KING Pro series

Brake lock: Supports one person fast installation to save 50% assembling and dissembling time and reduce labor cost.

Tightens the connection between led cabinets.

Competitors:
No brake lock: Generally two people work on installation. One people holds the cabinet and another operates locks




KING Pro Series:

Unique curved lock brings higher flatness and maks led displays a complete screen. support +5 degree and -5 degree
Competitors:
Normal design. The gap between led cabinets might be very obvious.




KING Pro Series:

Unique structure brings different shape to meet customers’ various requirements.




Hanging installation

Stacking installation
Product Packging

With rubber-protected around, 100% ensure the goods are safe.

Flight case will not be punctures or scratched.
Support silk printed logo.
FAQ
Q1. What’s fast delivery time?
The production can be controlled as fast as you need from 7 days to 25 days.Q2. Can I just wait for the items at my door and no need to do others?
Yes, items can be delivery to your specific address and you just wait for receiving the items at your door and nothing to do.Q3. The display will come to me in parts?and i have to install each part together?
Yes, but it’s quite easy. We will send you the instruction and also we can remote to help you to adjust the software, everything.Q4. What’s the function of video processor?
It can transfer the video source to make the screen performance more clear. Sometimes there has HD camera, so that the performance
can show themselves on the screen as well. Video processor can control stage lights together.Q5. How can I install the led display?
There are two options, one is hanging the display, the other is standing the display. Hanging bars and back stacking will be
provided.
